Precision NEXT Gen 6466 Reverse Rotation Turbo - 1000HP
Price Match Guarantee
Found it for less but value our service?
Details
Precision PTE NEXT Gen 6466, Reverse Rotation, Mirror Image Turbo, 1000HP, 2000HP Twin Turbos, Ball Bearing Turbochargers
Next Gen 6466 Reverse Rotation Turbo Features:
• Brand New Next Gen 7x7 CEA (Competition Engineered Aerodynamics) technology compressor wheel machined from a 2618 aluminum closed die forging for strength and optimized airflow
• Next Gen Aero Technology including an all-new flow enhancements to the compressor housing providing 10% more flow than previous Gen 2 turbocharger compressor covers
• High flow / highly efficient 66mm turbine wheel
• Air-cooled dual ceramic ball bearing center section (CHRA) for quick turbo response & durability
• Available in an All-New SCP compressor cover w/ 4” inlet and 2-1/2”outlet and for the first time in HP compressor cover w/ 4” inlet and 3”outlet for maximum air flow
Next Gen 6466 Mirror Image Turbo Specifications:
Compressor Wheel Inducer: 64mm
Compressor Wheel Exducer: 86mm/ 88.1mm Extended Tip
Turbine Wheel Inducer: 74mm
Turbine Wheel Exducer: 66mm
Ported S Cover PT6466 Next Gen Reverse Rotation Part Numbers:
51305229999 - R/R NEXT GEN PT6466 BB SCP CC SUPERCORE
51305229149 - R/R NEXT GEN PT6466 BB SCP CC W/ T3 STAINLESS V-BAND IN/OUT .82 A/R
51305229799 - R/R NEXT GEN PT6466 BB SCP CC W/ T3 STAINLESS V-BAND IN/OUT 1.05 A/R
Ported H Cover PT6466 Next Gen Reverse Rotation Part Numbers:
51307239999 - R/R NEXT GEN PT6466 BB HP CC SUPERCORE
51307239149 - R/R NEXT GEN PT6466 BB HP CC W/ T3 STAINLESS V-BAND IN/OUT .82 A/R
51307239799 - R/R NEXT GEN PT6466 BB HP CC W/ T3 STAINLESS V-BAND IN/OUT 1.05 A/R
More Information
| Part Number | 51305229149, 51305229799, 51307239149, 51307239799, 51305229999, 51307239999 |
|---|---|
| Brand | Precision Turbo |
| Type of Part | Next Gen |
| Length | 14 |
| Width | 12 |
| Height | 11 |
| Weight | 38.000000 |
