Pair of Precision NEXT Gen 6466 Mirror Image Turbos - 2000HP
Precision Mirror Image / Reverse Rotation turbocharger lineup has provided great performance throughout the years with lots of success stories between from customers around the world. After the success of our the Next GEN technology, it was just a matter of time before they applied their latest technology to the reverse rotation lineup. The first step will be upgrading the 6266 and 6466 turbochargers. The evolution of the lineup involves the development of a new aero package which includes a new compressor cover and a new compressor wheel improving flow by 10%. The new compressor design includes several new flow enhancements. The new compressor wheel involves various changes to the aero including an extended tip on the exducer.
HP Rating (pair): 2000hp respectively Next Gen Aero Technology including an all-new flow enhancements to the compressor housing providing 10% more flow than previous Gen 2 turbocharger compressor covers.
CEA (Competition Engineered Aerodynamics) compressor wheel machined from a 2618-aluminum closed die forging for strength & optimized air flow.
Air-cooled dual ceramic ball bearing center section (CHRA) for quick turbo response & durability.
Available in an All-New SCP compressor cover w/ 4” inlet and 2-1/2” outlet. The 6466 unit will also be available in the HP compressor cover w/ 4” inlet and 3”outlet for maximum air flow.
High flow / highly efficient 66mm turbine wheel.
6466 Next GEN Specifications:
• Compressor Wheel Inducer: 64mm
• Compressor Wheel Exducer: 86mm/ 88.1mm ET
• Turbine Wheel Inducer: 74mm
• Turbine Wheel Exducer: 66mm
6466 Next GEN Mirror Image Part Numbers:
Reverse Rotation:
51305229999 - R/R NEXT GEN PT6466 BB SCP CC SUPERCORE W/ NO TURBINE HOUSING
51305229149 - R/R NEXT GEN PT6466 BB SCP CC W/ T3 STAINLESS V-BAND IN/OUT .82 A/R
51305229799 - R/R NEXT GEN PT6466 BB SCP CC W/ T3 STAINLESS V-BAND IN/OUT 1.05 A/R
51307239999 - R/R NEXT GEN PT6466 BB HP CC SUPERCORE W/ NO TURBINE HOUSING
51307239149 - R/R NEXT GEN PT6466 BB HP CC W/ T3 STAINLESS V-BAND IN/OUT .82 A/R
51307239799 - R/R NEXT GEN PT6466 BB HP CC W/ T3 STAINLESS V-BAND IN/OUT 1.05 A/R
Standard Rotation:
27304210999 - S/R NEXT GEN PT6466 BB SCP CC SUPERCORE W/ NO TURBINE HOUSING
27304210149 - S/R NEXT GEN PT6466 BB SCP CC W/ T3 STAINLESS V-BAND IN/OUT .82 A/R
27304210799 - S/R NEXT GEN PT6466 BB SCP CC W/ T3 STAINLESS V-BAND IN/OUT 1.05 A/R
27307210999 - S/R NEXT GEN PT6466 BB HP CC SUPERCORE W/ NO TURBINE HOUSING
27307210149 - S/R NEXT GEN PT6466 BB HP CC W/ T3 STAINLESS V-BAND IN/OUT .82 A/R
27307210799 - S/R NEXT GEN PT6466 BB HP CC W/ T3 STAINLESS V-BAND IN/OUT 1.05 A/R
More Information
| Part Number | 27304210999, 27304210149, 27304210799, 27307210999, 27307210149, 27307210799, 51305229999, 51305229149, 51305229799, 51307239999, 51307239149, 51307239799 |
|---|---|
| Brand | Precision Turbo |
| Type of Part | Next Gen |
| Length | 27 |
| Width | 12 |
| Height | 11 |
| Weight | 38.000000 |
