2018-2024 Audi S4, S5 3.0T APR Carbon Fiber Intake
Price Match Guarantee
Found it for less but value our service?
Found it for less but value our service?
Details
2018, 2019, 2020, 2021, 2022, 2023, 2024, Audi, S4, S5 Sportback, 3.0T, Carbon Fiber Intake System, APR, CI100043
This is the ultimate intake upgrade for the Audi S4 and S5 (B9). It flows 31% more than stock, reduces pressure drop, and improves turbocharger efficiency. This directly translates to +19 AWHP and +20 AWFT-LBS of torque on top of our Stage 1 (93) tune making this a simple upgrade for more power you can feel.
The factory turbocharger inlet pipe is a big restriction point because it's small. It's common for most intake systems to only focus on the filter and airbox, but doing so only has minimal impact on performance. Furthermore, upgrading the turbocharger inlet pipe only has minimal impact on performance if it still necks down to with the factory or aftermarket intake airbox.
The airbox is fed from an inlet scoop that maximizes the flow path into the airbox. The airbox has cutouts allowing for additional flow paths directed away from the engine. This keeps air temps down, and increases sound without it being overbearing. The filter is massive as well. A big filter is desirable as increasing filtered surface area keeps the filter breathing easily for many miles as it filters dirt, dust, and particles. It measures 7" by 7" with a 5.5" frontal inlet, and a 4" outlet. The filter media is a washable pleated cotton gauze that can be cleaned for extended life, or replaced with ease.
Features:
- Full intake system: Inlet, airbox, filter, and inlet piping
- +19 AWHP & +20 AWFT-LBS gain over stock (APR Stage 1 93)
- Flows 31% more than stock
- Reduced pressure drop at the turbo inlets
- Improved linearization across the turbos
- Enhanced engine sound
- Carbon fiber construction
- Turbos spool faster
- Turbos operate more efficiently
- Massive 7” x 7” filter with a 4” outlet and 5.5” frontal inlet
- High flow and washable pleated cotton gauze filter material
- Airbox has additional flow paths faced away from the engine
- Inlet piping diameter is maximized from the 4” filter all the way to the turbocharger
- Inlet piping addresses system restriction, unlike competitive airbox systems that are compatible with factory inlet piping
- Billet turbo adapter ring make fitting this system to a larger turbo possible
- New OEM gaskets included
- Emissions friendly
More Information
| Part Number | CI100043 |
|---|---|
| Brand | APR |
| Type of Part | Intakes |
| Engine Fitment | 3.0L TFSI |
| Length | 24 |
| Width | 20 |
| Height | 18 |
| Weight | 10.000000 |
